P170

General Specifications

Audio frequency bandwidth 20 - 20000 Hz

Equivalent noise level 19 dB-A

Sensitivity 15 mV/Pa

Signal to Noise 75 dB-A

Preattenuation Pad -20 dB

Electrical impedance <= 200 Ohms

Recommended load impedance >=1000 Ohms

Polar Pattern Cardioid

Dimensions

Height 160 mm

Diameter 22 mm

Net Weight 130 g

Audio Output

Type Balanced XLR

Gender Male

Contacts 3-pin

Powering Interface

Voltage 44 to 52 V

Curent <= 3 mA

Application

Project Studio Yes

Live Instrument Yes

Instrument

Drums / Percussion Yes

Horns / Woodwinds Yes

Piano / Strings Yes

What's in the box?

• 1 x P170 Microphone

• 1 x Stand Adapter

Product Details

The P170 is a small-diaphragm condenser microphone for recording of overheads, percussion, acoustic guitars and other strings. Its lightweight 1/2-inch true condenser transducer diaphragm delivers outstanding clarity and transient response.

The P170 utilizes the experience of sound engineers from around the world and is considered an affordable alternative to the legendary AKG C451 B.
